A-PHY input
2-port Receiver with independently Configurable
MIPI A-PHY & HSMT standard PAL_I2C,PAL_CSI,PAL_GPIO
Support Coax/STP up to 15m at all speed
Downlink:2/3.2/4/6.4/8/12.8/16Gbps data rates
, Uplink: 100Mbps
MIPI CSI-2
Output
C/D-PHY Combo CSI x 2 Output
D-PHY can be configured as 2x4,4x2 lanes,Up to 2.5
Gbps per lane,up to 16 virtual channels
C-PHY up to 5.7Gbps/Lane, 2 lanes
I2C
Master and Slave mode 100KHz~1MHz
Clock output
Local precision CLK output
Package
QFN48, 7mmX7mm compatible with 3rd party
Temperature
Working temperature:-40℃~105℃
Qualification
AEC-Q100 Grade 2 qualified
