A-PHY
Support MIPI A-PHY & HSMT standard
Support PAL_I2C, PAL_CSI
Downlink:2/3.2/4/6.4/8Gbps data rates, Uplink: 100Mbps
Support Coax/STP up to 15m at all speed
MIPI CSI2
D-PHY CSl-2 input
4 data lanes, up to 2.5 Gbps per lane
Up to 16 virtual channels
I2C
Master and Slave mode 100KHz~1MHz
Clock output
Local precision CLK output
Sync Output
Output synchronize signals
Peripherals
2xI2C, 5xGPIO
Temperature
Working temperature:-40℃~105℃
Qualification
AEC-Q100 Grade 2 qualified
