A-PHY input
4-port A-PHY Receiver with independently Configurable
MIPI A-PHY standard PAL_I2C,PAL_CSI,PAL_GPIO
Support Coax/STP up to 15m at all speed
Downlink:2/4Gbps data rates, Uplink: 100Mbps
MIPI CSI-2
Output
C/D-PHY Combo CSI x 2 Output
D-PHY can be configured as 4+4,4+2,2+2 lanes,Up to 2.5
Gbps per lane,up to 16 virtual channels
C-PHY up to 5.7Gbps/Lane,3 lanes
I2C
Master and Slave mode 100KHz~1MHz
Clock output
Local precision CLK output
Peripherals
3xI2C, 16xGPIO
Package
QFN64, compatible with 3rd party
Temperature
Working temperature:-40℃~105℃
Qualification
AEC-Q100 Grade 2 qualified
